Key Technical Specifications 1. Engine & Power Engine Model: Weichai WD10G220E23 (or Shanghai Diesel SC11CB220G2B1 depending on target region) Rated Power: 162 kW (220 HP) @ 2200 rpm Engine Type: Inline 6-Cylinder, Water-Cooled, Turbocharged Diesel Engine Max Torque: 920 N·m Fuel Consumption Rate: Optimized low-speed energy-saving system 2. Operating Capacity & Performance Rated Load Capacity: 5,000 kg (5 Tonnes) Bucket Capacity: 2.5 m³ – 3.0 m³ (Standard is 3.0 m³) Operating Weight: 17,500 kg (17.5 Tonnes) Max Breakout Force: 175 kN Max Traction / Tractive Force: 160 kN – 165 kN 3. Dimensions & Working Range Overall Dimensions (L × W × H): 8,225 mm × 3,016 mm × 3,515 mm Max Dumping Height: 3,090 mm – 3,180 mm (High-dump options up to ~3,450 mm) Dumping Reach (at max height): 1,130 mm Wheelbase: 3,300 mm Tire Size: 23.5-25-16PR (Tubeless / Heavy-Duty Bias options) 4. Drivetrain & Hydraulics Drive System: 4-Wheel Drive (4WD) with planetary powershift transmission Transmission Gears: 2 Forward gears, 1 Reverse gear (countershaft/planetary style) Max Travel Speed: Forward: ~38 km/h Reverse: ~16.5 km/h Hydraulic Cycle Time: Raise time: ≤ 5.6 sec Total cycle time: ≤ 9.9 sec 5. Tank Capacities Fuel Tank: 230 Liters Hydraulic Oil Tank: 200 Liters Engine Oil: 20 Liters
